Loading spritesheets

The Graphic Entity Module can cut and handle spritesheets. There are two ways of doing that.

Using the SpriteSheetSplitter

This is the easiest way to create a set of sprites from a spritesheet. This solution is good for prototyping but it is performance costly.

For this example, we will use this spritesheet (taken from our free to use assets repository):

Spritesheet

  • 12 images
  • 4 images per row
  • Each of them is 128px wide and high
  • We want to use all the images starting from the top left corner, so the OrigRow and OrigCol must be set to 0
String[] seaweedSprites = graphicEntityModule.createSpriteSheetSplitter()
    .setSourceImage("spritesheet.png")
    .setImageCount(12)
    .setWidth(128)
    .setHeight(128)
    .setOrigRow(0)
    .setOrigCol(0)
    .setImagesPerRow(4)
    .setName("seaweed")
    .split();

//Creating an animation from the split spritesheet
graphicEntityModule.createSpriteAnimation()
    .setImages(seaweedSprites)
    .setX(50)
    .setY(50)
    .setLoop(true);

//Or a sprite from the 1st image of the spritesheet
graphicEntityModule.createSprite()
    .setImage(seaweedSprites[0])
    .setX(250)
    .setY(250);

It should look like this : Example

Using JSON sprites resources as assets

This method is slightly longer to setup but is more performant. In addition, this allows you to use spritesheets that are not necessarily in a grid layout.

First, you will need to generate a JSON Hash file. We suggest you use Leshy SpriteSheet Tool.

Your file should look like this.

sprites.json
{
   "frames":{
      "seaweed1":{
         "frame":{
            "x":0,
            "y":0,
            "w":128,
            "h":128
         },
         "rotated":false,
         "trimmed":false,
         "spriteSourceSize":{
            "x":0,
            "y":0,
            "w":128,
            "h":128
         },
         "sourceSize":{
            "w":128,
            "h":128
         }
      },
      "seaweed2":{
         "frame":{
            "x":128,
            "y":0,
            "w":128,
            "h":128
         },
         "rotated":false,
         "trimmed":false,
         "spriteSourceSize":{
            "x":0,
            "y":0,
            "w":128,
            "h":128
         },
         "sourceSize":{
            "w":128,
            "h":128
         }
      },
      ⋮
   }
}

Place this file in the assets folder, you can now use each image with their name as if they were split in different files.
